066

London ball valve, full flow

Female/female or male/female threads.
Body in nickel-plated brass.
Lever handle in steel (aluminium in the sizes 2”1/2, 3” and 4”) or T handle in aluminium or flat lever handle in lined steel.
Minimum and maximum working temperatures: -20°C, 60°C.
Female threads:
– ISO 7/1 Rp parallel (equivalent to DIN EN 10226-1 and BS EN 10226-1) sizes 1/4” through 2”.
– ISO228 (equivalent to DIN EN ISO 228 and BS EN ISO 228) sizes 2”1/2, 3” and 4”
Male threads:
– ISO 7/1 R taper (equivalent to DIN EN 10226-1 and BS EN 10226-1) sizes 1/4” through 2”.
– ISO228 (equivalent to DIN EN ISO 228 and BS EN ISO 228) sizes 2”1/2, 3” and 4”

SizePressureCodePacking
1/4" (DN 8)5bar/72.5psi066B01412/192
3/8" (DN 10)5bar/72.5psi066B03812/192
1/2" (DN 15)5bar/72.5psi066B01210/100
3/4" (DN 20)5bar/72.5psi066B0348/64
1" (DN 25)5bar/72.5psi066B1006/48
1"1/4 (DN 32)5bar/72.5psi066B1144/32
1"1/2 (DN 40)5bar/72.5psi066B1122/16
2" (DN 50)5bar/72.5psi066B2002/14
2"1/2 (DN 65)18bar/261psi1200212G1/5
3" (DN 80)16bar/232psi1200300G1/3
4" (DN 100)14bar/203psi1200400G1/2
