992
Gas leak detector with optical-acoustic alarm and relay control

AVAILABLE FOR METHANE GAS AND LPG.
Leds: power supply (green), failure (yellow), alarm (red).
Optical (red led) and acoustic (internal buzzer 87dBA) alarms.
Provided with realy output.
Power supply voltage: 230V.
Max electrical input: 20mA 230Vac.
Max relay contact load: 8A 250Vac/30Vcc.
Class of protection: IP42.
Working temperature: -10°C, 40°C.
Working relative humidity: 30%, 90%.
Alarm level: gas concentration equal to 10% of L.E.L. (Low Exposition Limit).
4 years after installation date the device must be put out of order and replaced with a new unit.
Dimension: 138x85x44 mm.
According to CEI UNI EN 50194.

SizeCodePacking
-992M1/12
SizeCodePacking
-992G1/12
