Adatte all’impiego in impianti idraulici, di riscaldamento, di condizionamento e pneumatici.
Attacchi filettati femmina/femmina/femmina.
Maniglia a leva in alluminio.
Corpo in ottone nichelato.
Temperature minima e massima d’esercizio: -10°C, 120°C in assenza di vapore.
Attacchi filettati: ISO 228 (equivalente a DIN EN ISO 228 e BS EN ISO 228).
| Misura | Pressione | Codice | Imballo |
|---|---|---|---|
| 1/4“ (DN 8) | 55bar/797.5psi | 1280014L | 4/32 |
| 3/8“ (DN 10) | 55bar/797.5psi | 1280038L | 4/32 |
| 1/2“ (DN 15) | 50bar/725psi | 1280012L | 4/32 |
| 3/4“ (DN 20) | 50bar/725psi | 1280034L | 2/16 |
| 1“ (DN 25) | 45bar/652.5psi | 1280100L | 2/12 |
| 1“1/4 (DN 32) | 35bar/507.5psi | 1280114L | 2/6 |
| 1“1/2 (DN 40) | 35bar/507.5psi | 1280112L | 2/6 |
| 2“ (DN 50) | 35bar/507.5psi | 1280200L | 1/4 |
| Misura | Pressione | Codice | Imballo |
|---|---|---|---|
| 1/4“ (DN 8) | 55bar/797.5psi | 1280014T | 4/32 |
| 3/8“ (DN 10) | 55bar/797.5psi | 1280038T | 4/32 |
| 1/2“ (DN 15) | 50bar/725psi | 1280012T | 4/32 |
| 3/4“ (DN 20) | 50bar/725psi | 1280034T | 2/16 |
| 1“ (DN 25) | 45bar/652.5psi | 1280100T | 2/12 |
| 1“1/4 (DN 32) | 35bar/507.5psi | 1280114T | 2/6 |
| 1“1/2 (DN 40) | 35bar/507.5psi | 1280112T | 2/6 |
| 2“ (DN 50) | 35bar/507.5psi | 1280200T | 1/4 |
